White Offset Printing PVC Card Base Material Core Sheet For Smart Card Production
Production Deatails
| 1. White Offset Printing PVC Card Base Material Core Sheet For Smart Card Introduction |
This kind of ordinary PVC sheet can be used for laminating, non-laminating, printing, coating and
cutting, such as membership cards and calendars.
White Offset Printing PVC Card Base Material Core Sheet For Smart Card MOP series are designed for offset printer and silk screen printer use. They can also be used as non-printed middle core sheet. They are massively used by many card factories worldwide.
1) Suitable for the whole series of offset printer.
2) High definition images.
3) Excellent ink adhesion with strong peeling strength after lamination.
4) No crack occurs on the printed images after lamination at high temperature.
Product Advantage:
1. Smooth and Uniform Surface
It is waterproof and has very good smooth surface, and is non-deformable.
2. Reliable Electrical Insulation
It is widely used for different electrical equipment.
3. Excellent Chemical and Corrosion Resistance
It can withstand the erosion of a variety of chemicals.
4. Good Impact Resistance
It has good impact resistance, pressure-resisting and durability.
5. Easily Formed
It is easily formed due to good plasticity, which is suitable for die cutting, vacuum forming and folding.
6. Wide Usage
It can be laminated with uncoated overlay film after uv offset priting.
| 2. White Offset Printing PVC Card Base Material Core Sheet For Smart CardSpecification |
White Offset Printing PVC Card Base Material Core Sheet For Smart Card with good ability of lamination and printing.
| Item | Unit | Value |
| Thickness | mm | 0.10-0.85 |
| Density | g/cm3 | 1.42 ±0.05 |
| Tensile Strength | Horizontal | MPa | ≥44 |
| Vertical | ≥46 |
| Vicat 5kg | ℃ | 80±2 |
| Surface Roughness | Ra | μm | 0.7~1.8 |
| Rz | 4.0~12.0 |
| Surface Dyne | dynes/cm | ≥34 |
*Customer design can be accept.
Technical parameters:
1. Thickness: 0.12-0.76mm
2. Color: Milk White (MOP-W-NF model)/Snow White MOP-W-F model
3. Suitable printer models: The whole series of offset printer
4. Package method: 100-200 sheets per PE bag, all the bags are firmly piled up and fixed on the solid plywood pallets.
5. Storage condition: Sealed, moisture-proof, room temperature under 40℃
| Item | Index |
| Tensile strength | Longitudinal MPa | ≥45 |
| Transverse MPa | ≥40 |
| Vicat ℃ | 77±2 |
| Surface Tension dyne / cm | ≥35 |
| Heat shrinkage rate% 140℃ 10min | Transverse ≤5 |
| Longitudinal ≥-10 |
| Squareness mm | ±1 |
| Thickness tolerance % | ±5 |
| Roughness μm | Ra,μm | 0.7~1.4 |
| Rz,μm | 4~9 |
| 3. Application of White Offset Printing PVC Card Base Material Core Sheet For Smart Card |
White Offset Printing PVC Card Base Material Core Sheet For Smart Card is mainly used for making credit card. Such material can achieve telegraphing
(embossed), the material does not contain the substance for entering and modifying magnetic materials,
capable of being labeled with magnetic stripe and encapsulated module, usually, it is matched with
overlay film for use. PVC Bank Card Base is mainly used for bank, capable of making credit card, financial IC card.
| 4. Packing of Plastic PVC Card Core Sheet As Non-printed Middle Sheet Smart Card Materials |
In standard export carton and are packed on plywood pallet
Product Tags:
|
|
White Offset Printing PVC Core Sheet With Smooth And Uniform Surface Images
|
